Title DYE NGX2 HERCULEAN HEAVY DUTY BEASTS
Make DYE
Sale Price POA
Listing Type New
Stock Number DYE1503
RefCode TA646239

Description

The name says it all!!
Herculean by name Herculean by nature!!
Seventy years of manufacturing knowledge. Dye...built to last.

These machines are totally customisable to suit client applications. Exceptional value for money. We challenge you to find better.

The NGX2 series is manufactured with attention to detail and is available in multiple configurations and axis ability built to your requirements. These are fully synchronised CNC machines.

Dye offers the consumer highly accurate, reliable and tough machines built to last without compromise on quality. Customisable, they ensure high flexibility, productivity and profitability for your investment dollar. Need something special, we provide performance and value for money.

The powerful yet simple Cybelec controls offer the ability to control 2-18 axes and will automatically calculate the bend sequence, bend angle, back gauge retraction, bend allowance, automatic crowning and features collision protection with graphical simulation, network capable (control model dependant), and available with offline programming software. Delem controllers available on request.

With automatic calibration and precise positional control to + - 0.005 mm accuracy make the NGX2 a great partner for the production of precision components, both large and small batch runs..


Our Standard Features include

  • Including pump motor soft starter, monitored hydraulics, full guarding, etc
  • Twin synchronised drop forged cylinders with high performance European hydraulics
  • High quality linear glass encoders with a resolution of .005mm
  • C frame encoder mounting to compensate for side frame deflection
  • Hydraulic operation with protection by relief valve
  • Quiet internal gear pump ensures low noise
  • Heat treated stress relieved heavy duty steel frame with machined load bearing surfaces in one set up on high quality European machining centres ensuring rigidity and accuracy.
  • Double guides on the top beam
  • Dye ADS Hydraulic Crowning System automatically calculated by the control.
  • Cybelec controls offered CYBTOUCH 12, 15 2D, VISIPAC 19 2D & VISIPAC 19 MX 3D.
  • Multiple axes configurations from 4-18 axes.
  • Heavy Duty linear bearings on back gauge runners mounted on side frames. Back gauge travels to client specifications.
  • Standard throat 610mm or larger throats on request.

Optional Features
  • X for X axis back gauge
  • XR Heavy duty X&R back gauge with rear adjusted manual Z probes
  • Back gauge travels available on request
  • Special throat depths.
  • Rear safety fence standard. Light curtain available on request.
  • Hydraulic clamping system
  • Front Sheet Supports
  • Front Gauging
  • Lazersafe or AKAS laser guarding
  • Robotic integration (control dependant)
