DEUTZ-FAHR 4060E KEYLINE HD ROPS

Engine
SDF 1000 Series Tier 3 Diesel Engine
3 Cyl/3000cc Turbocharged Intercooled
Liquid/Oil Cooled
Individual Bosch Injector Pumps
60Hp @ 2350 rpm (2005/25/CE)
Torque 221nm
Up Swept Side Exhaust
55lt Fuel Capacity

Transmission
12/12 Synchromesh Gearbox
Forward/Reverse Synchro Shuttle
Shuttle Lever Mounted on Steering Column
Creep Range STD
Double Dry Heavy Duty 11 Clutch
Heavy Duty Rear Axle
Rear Wheel Girling Brake System
Front Wheel Assist
Heavy Duty SDF Front Axle
Front & Rear Diff Lock
35 km/h Road Speed

PTO
Independent Rear PTO
540 Speed PTO
540 @ 1965 Rpm
13/8 -6 Spline PTO shaft

Operator Environment
2 Post Foldable ROPS Frame
Flat Platform
Rubber Floor Mat
Deluxe PVC Mechanical Seat
Sun Canopy
1 Rear Work Light
2 Bonnet Lights with Hi/Lo Beam

Hyd/Linkage/Drawbar
Open Centre Hydraulic System
31 l/min Hyd Pump
Separate 17 L/min Steering Pump
2 Sets of Remotes 1 Detent / 1 Spring
Mechanical Three Point Linkage
Position & Draft Control Settings
CAT 2 Ball ends
1600kg lift capacity
Swinging Drawbar CAT A

Wheel Equipment & Miscellaneous
Fully Adjustable Wheels
11.2*20 Front -14.9*28 Rear Ply Tyres
172Kg Rear Wheel Weights

Weights & Dimensions
Wheelbase 1950mm
Overall Length 3513mm
Overall Width 1831mm
Overall Height 2460mm
Total Weight 2860kg
